Details description

● The 2.75-inch resolution is 240*400 touch LCD color screen, the interface is simple, and the operation is more humanized;

● 4 sets of microphone inputs, each group can independently adjust feedback suppression and 7-band parametric equalization, and set high-pass filter/low-pass filter/dynamic compression/excitation function/noise gate;

● 2 groups of music input, each set has 7-parameter equalization, with internal lifting/high-pass filtering/low-pass filtering/dynamic compression;

● Echo and reverb have 7-parameter equalization, and independently deliver volume to each output;

● 8-channel independent output, each channel can adjust 7-band parametric equalization, with high-pass filter/low-pass filter/voltage limit function/delay function/inverting function;

● Routing bus function, microphone, music to each output is arbitrarily assigned;

● Built-in sine wave / pulse / square wave / white noise / sweep / pink noise signal generator;

● New generation DSP technology, powerful and efficient;

● Multiple online modes: WIFI/USB, support remote control

● It can store 10 kinds of preset parameters, optical fiber and coaxial digital signal input interface;

● Suitable for stage performances, home theaters, KTV rooms and conference rooms.

technical parameter

● Signal to noise ratio: MIC: 115dB, MUSIC: 116dB

● Distortion: ≤0.005% (20Hz~20KHz)

● Frequency response: 20Hz~20KHz (+-2dB)

● Maximum input level: MIC: -11.4dbu, MUSIC: +2.76dbu

● Maximum output level: MIC: +14.9dbu, MUSIC: +14.8dbu

● Input impedance: MIC: 10K Ohm, MUSIC: 22K Ohm

● Output impedance: 300 Ohm

● DSP processor: 32bit

● AD/DA: 192KHz 24bit

● Size : 545x488x405mm

● Power supply voltage : AC 100-240V 50/60Hz
