Details description

● The 2.2-inch resolution is 176*220 touch LCD color screen, the interface is simple, and the operation is more humanized;

● 4 groups of microphone inputs, each group can independently adjust 15 segment parametric equalization, with high-pass filtering/low-pass filtering;

● The microphone input is equipped with dynamic compression/excitation/feedback suppression/noise gates;

● The music input has 7-parameter equalization, with high-pass filtering/low-pass filtering/dynamic compression/excitation function inside;

● Reverb has 3 independent parameter equalization, high-pass filtering and low-pass filtering;

● 6 channels independent output, each channel can adjust 7-band parametric equalization, with high-pass filter/low-pass filter/voltage limit function/delay function/inverting function;

● Manual/auto mode to switch the singing/hot dance mode;

● With WIFI, USB function interface, online is more convenient and faster;

● Customize the screen saver password to prevent modification of preset parameters.

● 32bit high performance DSP with wider frequency band and larger dynamic range;

● It can store 10 preset parameters and support remote control control;

● Suitable for stage performances, home theaters, KTV rooms and conference rooms.

technical parameter

● Signal to noise ratio: MIC: 113dB, MUSIC: 115dB

● Distortion: ≤ 0.005% (20Hz~20KHz)

● Frequency response: 20Hz~20KHz (+-2dB)

● Maximum input level: MIC: -11.2dbu, MUSIC: +2.73dbu

● Maximum output level: MIC: +14.8dbu, MUSIC: +14.8dbu

● Input impedance: MIC: 10K Ohm, MUSIC: 22K Ohm

● Output impedance: 300 Ohm

● DSP processor: 32bit

● AD/DA: 192KHz 24bit

● Size: 432x235x45mm

● Power supply voltage: AC 220V/50Hz ±10%
