Details description

● 2 groups of microphone inputs, each group can independently adjust 22-band parametric equalization, with high-pass filtering/low-pass filtering;

● The microphone input is equipped with dynamic compression/excitation function/8-level feedback suppression/noise gate;

● Music input has 15 sections of parameter equalization, with high-pass filtering/low-pass filtering/dynamic compression;

● The main output and the rear output are provided with 10-band parametric equalization, central output, and ultra-low with 7-band parametric equalization;

● With variable adjustment function, all outputs can set the pressure limit delay function;

● Optional WIFI receiving module, USB function interface, online is more convenient and faster;

● Customize the screen saver password to prevent modification of preset parameters.

● 32bit high performance DSP with wider frequency band and larger dynamic range;

● 10 preset parameters can be stored;

● Support remote control, optical fiber, coaxial input interface;

● Suitable for stage performances, home theaters, KTV rooms and conference rooms.

technical parameter

● Signal to noise ratio: >100dB

● Total harmonic distortion: MIC<0.1% / MUSIC<0.05%

● Maximum input level: 4V RMS

● Maximum output level: 4V RMS

● Music channel gain: ≤12dB

● Microphone sensitivity: 64mV (out: 4V)

● Dynamic range: MIC>80dB / MUSIC>110dB

● Size: 484x200x48mm

● Power supply voltage: AC 220V / 50Hz ±10%
