Details description

● Configure 4-inch resolution 800*480 touch LCD color screen for fast and efficient operation;

● 10 channels of signal input, each group can independently adjust 7-band parametric equalization, with high-pass filtering/low-pass filtering/

    Dynamic compression/excitation function/feedback suppression;

● Echo and reverb have 7-parameter equalization, and independently deliver volume to each output;

● 8-channel independent output, each channel can adjust 7-band parametric equalization, with high-pass filtering/low-pass filtering

      Noise gate/compressor/inverting function/delay function;

● Routing bus function, input signal to each output is arbitrarily allocated;

● Built-in sine wave / pulse / square wave / white noise / sweep / pink noise signal generator;

● High power and high computing DSP technology, high resolution 24Bit AD/DA, ensuring unlimited internal dynamic range;

● 192KHz sampling frequency, high quality compression, delay, etc.;

● A variety of online mode support work, WIFI / USB interface function, built-in USB sound card;

● 32bit high performance DSP with wider frequency band and larger dynamic range;

● Suitable for stage performances, bars, home entertainment, internet karaoke and other occasions.

technical parameter

● Signal to noise ratio: MIC: 114dB, MUSIC: 116dB

● Distortion: ≤0.005% (20Hz~20KHz)

● Frequency response: 20Hz~20KHz (+-3dB)

● Maximum input level: MIC: -11.3dbu, MUSIC: +2.75dbu

● Maximum output level: MIC: +14.8dbu, MUSIC: +14.9dbu

● Input impedance: MIC: 10K Ohm, MUSIC: 22K Ohm

● Output impedance: 300 Ohm

● DSP processor: 32bit

● AD/DA: 192KHz 24bit

● Size: 396x276x72mm

● Power supply voltage: AC 100-240V 50/60Hz
