Details description

● Configure 7-inch resolution 1024*600 touchable LCD color screen, fast and efficient interface operation;

● 22-channel audio input, 2 channels of stereo, built-in 10-channel AUX;

● Powerful matrix mixing capability, flexible and changeable;

● Input channels are equipped with 5-band parametric equalization, high-pass filtering/low-pass filtering/noise gate/compressor/inverting function/delay function;

● High power and high computing DSP technology, high resolution 24Bit AD/DA, ensuring unlimited internal dynamic range;

● 192KHz sampling frequency, high quality compression, delay, etc.;

● 100MM high resolution putter;

● Multiple online modes, WIFI/USB interface function;

● Suitable for stage performances, bars, KTV rooms and large conference halls.

technical parameter

● Signal to noise ratio: MIC: 113dB, MUSIC: 115dB

● Distortion: ≤ 0.005% (20Hz~20KHz)

● Frequency response: 20Hz~20KHz (+-3dB)

● Maximum input level: MIC: -11.2dbu, Music: +2.73dbu

● Maximum output level: MIC: +14.8 dbu, Music: +14.8 dbu

● Input impedance: MIC: 10K Ohm, Music: 22K Ohm

● Output impedance: 300 Ohm

● DSP processor: 32bit

● AD/DA: 192KHz 24bit

● Power supply voltage: AC 220V / 50 Hz ±10%
