Details description

● 8 channels of input, 3 sections of EQ, warm tone and strong musicality;

● High quality, low noise balanced microphone input with +48V phantom power supply;

● Two AUX auxiliary outputs; external processor can be connected;

● High-precision three-color precision level column to accurately display the output level;

● Built-in squelch switching power supply, easy to use and flexible;

● Built-in DSP chip (99 professional benchmark effects) with mode display light;

● Configure MP3 module, support Bluetooth receiving, USB input interface, automatically recognize and play MP3 music;

● High-quality components and extremely strong structure make the product durable;

● Suitable for stage performances, bars, KTV rooms and large conference halls.

technical parameter

● Total harmonic distortion: <0.005%

● Frequency response: 20Hz-20KHz +1dB /-3dB

● Maximum output level: 18dBm (1 KHz, THD=0.5%)

● Signal to noise ratio: <81 dB

● Gain control: 51dB~0dB; Stereo: -26dB~0dB

● Residual output noise: <-83dBu

● Crosstalk: <-79dBu

● Headphone output power: 260mW (1KHz, THD=0.5%, 200Ω)

● Input and output impedance: MIC input: 2.4KΩ, Mono: 11 KΩ, Stereo: 100 KΩ

● Output impedance: ≤75Ω

● Power supply voltage: AC 220V /50Hz ±10%
