Details description

● Simple appearance design, excellent heat dissipation effect;

● Class D digital amplification structure, high efficiency, energy saving;

● Powerful output capability, low frequency, strong and medium frequency, round and sweet mid-frequency, high-frequency clear and delicate;

● Balanced input XLR stereo with stereo and bridge modes of operation;

● Independent limiting, overload, overheat and short circuit protection circuits;

● Adopt NTC soft start to boot, with PFC regulator circuit;

● Each channel has independent overvoltage, overheat protection, load short circuit and other protection functions;

● Automatic limiting function prevents damage to the speaker;

● Suitable for stage performances, KTV rooms and conference rooms.

technical parameter

● Rated output power Stereo: 1000W*2/8Ω

                         800W*2/4Ω

● Bridging: 3600W/8Ω

       4000 W/4Ω

● Frequency response: 20Hz-20KHz (±1dB)

● Total harmonic distortion: <0.1%

● Signal to noise ratio: 95dB

● Conversion rate: >20V/μs

● Input impedance: Balance 20KΩ / Unbalanced 10KΩ

● Amplifier topology type: Class D

● Dynamic range: ≥95dB

● Input sensitivity: 2Vrms

● Size: 480x225x50mm
