Details description

● 5 groups of music and 3 microphone inputs;

● Automatic switching of audio and video input;

● Exposed knob adjustment, easy to operate, easy to use;

● One-key switching of audio input, minimum signal loss, high-fidelity sound quality and K-song sound effects;

● Classic enthusiast grade circuit design, wider frequency response;

● Using advanced digital reverberation chips, vocal performance is better;

● Suitable for home theater, KTV rooms and conference rooms.

technical parameter

● Rated output power: 200W*2/8Ω

● Total harmonic distortion: 20Hz-20KHz (±0.2dB)

● Frequency response: 20Hz-20KHz ±0.2dB

● Signal to noise ratio: >100dB

● Rated output level / impedance: 750Mv / 47KΩ

● Dynamic coil: 350mV/10kΩ

● Capacitance: 200mV/100kΩ

● Video: 1V (p-p RMS) / 75

● Reverberation delay: 200mS MAX

● Size: 483x485x88.5mm

● Input voltage (V): AC220V / 50Hz ± 10%
